Advanced Steel Detailing & 3D Modelling
Our steel detailing and modelling workflow combines precise 3D environments with disciplined drawing standards to produce erection plans, shop drawings and CNC outputs that fabricators and site teams can trust. Every member, connection and bolt is coordinated to reduce clashes, RFIs and on-site improvisation.
From industrial frames to commercial buildings and complex trusses, we focus on buildability, clear communication and predictable sequences. The result is smoother fabrication, cleaner site assembly and a steel package that supports schedule certainty and safer construction.
Our Capabilities
3D Steel Modelling
Member-by-member 3D models with precise sections, grids and levels, ready for drawing extraction, clash review and coordination.
Shop & Erection Drawings
Clear piece drawings and erection plans that guide fabrication and site crews with logical numbering and mark systems.
Connections & Anchors
Connection details, anchor bolt plans and base plate layouts aligned with engineering design and fabrication practices.
NC Data & Documentation
CNC-ready data (DSTV / NC files), bolt lists and material summaries prepared to accelerate production workflows.
Our Methodology
Input Review & Strategy
We review design drawings, specifications and connection philosophies, clarifying open points before modelling begins.
- Design intent clarification
- Connection strategy alignment
- Project standards setup
3D Modelling & Connections
Members, bracings and connections are built in 3D with controlled levels, grids and naming for consistent extraction.
- Primary & secondary framing
- Connection detailing
- Preliminary clash checks
Drawings & NC Outputs
We generate shop and erection drawings, bolt lists and CNC files aligned with fabrication and erection sequences.
- Piece & assembly drawings
- Anchor bolt & base plate plans
- DSTV / NC & material lists
QA Review & Handover
Multi-level checks validate geometry, marks and quantities before final issue to fabricators and site teams.
- Internal model checks
- Drawing & list verification
- Packaged digital handover
